8Sinn 15mm Baseplate

$145.95 USD
Free shipping for orders $100 above (USA)

KEY FEATURES

  • 2 × 32mm Arri rosettes for handle or arm attachment
  • 15mm rod compatibility (LWS standard)
  • 3 × thumbscrews for secure rod and plate locking
  • 6 × 1/4" threaded openings for versatile mounting
  • Dovetail guide rails (bottom) for Arri plate connection
  • Compatible with Riser Plate I, Basic, and II
  • Precision-milled aluminum construction
Overview

The 8Sinn 15mm Baseplate serves as the foundation of a complete filmmaking setup. Its design allows easy integration with the Riser Plate I, Riser Plate Basic, or Riser Plate II, ensuring proper lens height and secure rig assembly.

The 15mm LWS rod clamp system supports any standard 15mm rods (stainless, carbon, or aluminum) and provides solid, adjustable tightening for stable camera configurations.

Equipped with two 32mm Arri rosettes, this baseplate lets you mount side handles or arms for enhanced ergonomics and control.

The dovetail guide rails at the bottom allow smooth sliding adjustments on Arri-style plates, while six 1/4" threaded openings give flexibility for mounting accessories.

Its three thumbscrews provide reliable locking and quick setup, making it a versatile, heavy-duty core for professional rigs.
What's Included

1pc 8Sinn 15mm Baseplate
Full Specifications

Dimensions

  • Length: 120mm
  • Width: 81mm (108mm with the thumbscrews)
  • Height: 32mm
  • Weight: 212g
