GKJRC Katana Pro Gimbal Head Telephoto Lens Side Mount Clamp

$534.95 USD

Free shipping for orders $100 above (USA)

KEY FEATURES

  • Max load capacity: 50 lbs
  • Height: 9.75 inches
  • Weight: 1.8 lbs
  • Smooth panning and tight locking mechanism (separate from assembly mounts) so you can adjust the friction without parts coming apart
  • Arca-Swiss type compatible lens mount
  • Hard anodized scratch-resistant finish
  • Sealed Maintenance Free Ball Bearings
  • Oversized knobs
  • Lightweight aircraft quality aluminum
  • CNC Precision machined parts
  • 5-year warranty
  • Made in the USA
Overview

The ProMediaGear GKJRC Katana Pro Gimbal Head with side mount clamp works the same as the regular Katana Pro with a cradle mount. However, the difference is in the mounting system.

This version has a side mount clamp, which means that the camera is directly attached to the vertical pivot point.

Compared to a cradle mount, the GKJRC Katana Pro side mount clamp version does not have as much mobility as the standard cradle mount. This is because it centers the lens around the axis of rotation at the vertical pivot.

There is an advantage to a side clamp gimbal head though - weight. This gimbal head is less bulky. It is easier to transport from one place to another.

Functionality is the same as the regular Katana Pro Gimbal Head. It is stable and can carry large lenses.

ProMediaGear creates these gimbal heads with T6061 aircraft-grade aluminum making them lightweight, durable, and easy to carry. Fluidity is no problem as well due to the sealed bearings.

What's Included
  • GKJr. Katana Pro Gimbal Head with Side mount clamp
  • PX6 mounting/balancing plate $40 value.
  • 5-year warranty
  • Made in the U.S.A.
Full Specifications
  • Length: 8.48 inches
  • Width: 3.10 inches (including knob)
  • Height: 9.75 inches
  • Weight: 1.8 pounds
  • Load Capacity: 50 lbs (22 KG)
  • Mount Thread: 3/8'-16
  • Mounting Base: 2.36 inches
What is the difference between the GKJr Katana Pro and the GK Katana GImbal Head?

The main difference between the two models is the size. The Katana Pro is more portable due to its smaller footprint.

If you have extremely large lenses and heavy setup, then the GK Katana is for you. But, if you value portability, then the GKJr Katana Pro is the one.

Will the clamp work with other brands?

Yes, the GK Katana and GKJr Katana Pro has a regular Arca-swiss clamp that allows you to use any camera accessories that has an Arca-swiss plate.

What is a side clamp gimbal?

It works by having the camera pivot up and down by its side while panning left to right through the gimbal mount.
